VW Type 4 Carb Linkage for Type 4 engine with stock or upright fan housing, with Weber IDA, IDF and Dellorto carburetors.

This Pushrod Carb Linkage system has build in “ Quick Release “ which attached to both sides of the carburetor, allowing for removing / fitting without the need to unscrew the linkage and resetting.

• The linkage is mounted on the engine case, longer bolt is required and included.
• The location of the Throttle Cable required to be the same as standard late type 1 engine, i.e. 1200 ~ 1600 cc type 1 engine.
• Dual ball bearing with return spring included.
• Long threaded pushrod that can be fit to wide range of carburetors.
• Build in Quick Release link ball system, easy to remove intake without the need to adjust the linkage again and again.
• Will not increase the idle speed when the engine running hot.

 Vintage Speed # 155-401-031                              V66
